RUIJIE- AC1300 Dual Band Wall-Plate Access Point
300 ريال 250 ريال خصم 16%الوصف | معلومات اضافية
RUIJIE- AC1300 Dual Band Wall-Plate Access Point
| اسم العلامة التجارية: | RUIJIE |
| مديل المنتج: | RG-RAP1200(F) |
| نوع المنتج: | RUIJIE- AC1300 Dual Band Wall-plate Access Point |
| مواصفات المنتج: | Please refer Datasheet on Manufacturer Website |
| الضمان: | Manufacturer Standard Warranty. |
DESCRIPTION
RUIJIE– AC1300 Dual Band Wall-plate Access Point
Details:
RUIJIE– AC1300 Dual Band Wall-plate Access Point
Ruijie Reyee Series RG-RAP1200(F) dual-band FE wall plate AP is a high-performance wall plate AP. With 802.3af/at PoE support, the AP provides a?LAN port at the front to facilitate the expansion of IPTV, IP phone, etc. Compliant with 802.11a/b/g/n/ac Wave1/Wave2 Wi-Fi protocol, the AP supports?MU-MIMO dual-stream technology and offers built-in omnidirectional antennas. It can operate concurrently at 2.4GHz and 5GHz, providing high-speed?wireless access of 400Mbps at 2.4GHz, 867Mbps at 5GHz and up to 1267Mbps per AP. Its compact 86mm wall plate installation design facilitates quick?installation directly into a standard 86mm wall junction box, which is an ideal choice for deployment such as offices, commercial industry, hotels, service scenarios, etc.
The AP supports Ruijie?s self-organizing network feature, which means to realizes auto-discovery, auto-networking and auto-configuration between routers,?switches, and wireless APs without the need for controllers or Internet access. With the Ruijie Cloud app, users can quickly complete the device deployment?and configuration, remote management, operation and maintenance of the entire network, which greatly reduces the investment of equipment cost, labor cost?and time cost in the process of wireless network construction.
Key Features:
- 802.11ac Wave2 technology
- Auto-provisioning via Self-Organizing Network?Supports Ruijie?s self-developed smart networking feature, which breaks through the product limitations and realizes auto-discovery, auto-networking and auto-configuration between gateways, switches, and wireless APs without the need for controllers or Internet access;
- Lifetime free Ruijie Cloud management: Remote fault alarm, one-click optimizing and maintenance on Ruijie Cloud App;
- Seamless layer 3 roaming
- Industrial Design: Robust casing, Provide better strength and safety for products;
- High-speed dual-band Wi-Fi
- Support routing and AP mode
- Support Layer 3 networking
- Stronger and more stable signals
- Multi-way management
- Remote collaborative management
- Al & big data network optimization
Technical Specifications:
| Hardware specifications | |
| Radio | Dual-stream dual-band |
| Protocol | Concurrent 802.11b/g/n/ac |
| Operating Bands | 802.11b/g/n ?2.4G ~ 2.4835GHz
802.11a/n/ac ? 5G?5.150?5.350GHz?5.47?5.725?5.725?5.850GHz (Note: The operating bands vary according to different countries) |
| Antenna | PCB antenna |
| Spatial Streams | 2.4G: 2 Spatial Streams,2×2 MIMO
5G: 2 Spatial Streams,2×2 MIMO |
| Max Throughput | 2.4G: up to 400Mbps
5G: up to 866.7Mbps |
| Modulation | OFDM: BPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, and CCK@5.5/11Mbps MIMO-OFDM: BPSK, QPSK, 16QAM, 64QAM and 256QAM |
| Receive Sensitivity | 11b?-97dBm(1Mbps) ?-92dBm(5Mbps) ?-89dBm(11Mbps)
11a/g?-94dBm?6Mbps??-85dBm?24Mbps??-82dBm?36Mbps??-76.5dBm?54Mbps? 11n?-93.5dBm@MCS0?-74dBm@MCS7?-74dBm@MCS15 11ac?HT20?-92.5dBm?MCS0?, -68.5dBm?MCS8? 11ac?HT40?-89dBm?MCS0?, -64dBm?MCS9? 11ac?HT80?-86dBm?MCS0?, -60.5dBm?MCS8? |
|
Maximum Transmit Power |
20dBm (adjustable) |
|
Adjustable Power |
1dBm |
|
Dimensions |
86*86*29.3 |
|
Weight |
<0.25kg |
| Service Ports | Front? 1 10/100Mbps Ethernet portRear? 1 10/100Mbps PoE Ethernet port |
| Management Port | N/A |
| LED Indicator | Support |
| Power Supply | Support 802.3af power supply |
| Power Consumption | ?8W |
| Environment | Operating temperature: 0?C?40?C |
| Storage temperature: -40?C?70?C | |
| Operating humidity: 5??95??non-condensing? | |
| Storage humidity: 5??95??non-condensing? | |
| Installation | 86mm wall plate installation |
| IP Rating | IP41 |
| Safety Standard | GB4943, IEC62368-1 |
| EMC Standard | GB9254?EN301 489?EN50155?EN50121?EN55032?EN61000?EN55035 |
| Vibration Standard | IEC61373 |
| Radio Standard | EN300 328, EN301 893 |
| Software Features | |
| Operating Mode | AP mode and routing mode |
| WLAN | Maximum number of clients: 110 |
| Recommended number of clients: 40 (8 at 2.4GHz, 32 at 5GHz) | |
| Up to 8 SSIDs | |
| Support SSID hiding
Configuring the authentication mode, encryption mechanism, and VLAN attributes for each SSID |
|
| SSID-based and radio-based STA limit | |
| Support Layer 2 user isolation | |
| Roaming | Support Layer 2 and Layer 3 roaming |
| Security | Support PSK authentication |
| Support static blacklist and whitelist | |
| Support WPA (TKIP), WPA2 (AES), and WPA-PSK data encryption | |
| Routing | Support static IP address, DHCP, PPPoE Dial Up |
| Management and maintenance | Support unified networking of all network equipment
Support local or remote management with Ruijie Cloud app Support local management with web Support remote management with Ruijie Cloud platform |
| Platform management features | Automatic RF adjustment via the platform |
| Unified configuration via the platform | |
| Unified monitoring via the platform | |
